Introduction

Built for Water. Engineered for Intelligence.

AERINOS ADS-300 Nautilus is an IP68-rated, fully submersible, ultra-low-power NB-IoT / LTE-M telemetry RTU designed for water level, water quality and remote sensor monitoring. Its marine-grade construction and stainless steel 316 connectors support demanding water and marine installations, including locations without mains power.

The unit combines an integrated cellular modem, USB serial interface, one digital input/counter, one 12-bit analog input, an optional three-axis accelerometer and a Coulomb meter for battery consumption monitoring. It acquires measurements from SDI-12 and RS-485 Modbus sensors and provides selectable excitation for powering compatible external sensors.

Fully submerged, marine-grade construction

The rugged IP68 enclosure is designed for fully submerged operation, with stainless steel 316 connectors for corrosion resistance in demanding marine environments. ADS-300 Nautilus was tested for five months fully submerged in 1 metre of water, transmitting every 15 minutes.

SDI-12 Serial Bus

ADS-300 Nautilus complies with SDI-12 version 1.3 and collects up to 15 measurement channels from multiple compatible sensors, bringing water level and water quality measurements into your telemetry system.

RS-485, Modbus

The RS-485 interface supports acquisition from Modbus sensors, with up to 10 measurement channels using Modbus ASCII.

Transducer excitation

A user-adjustable excitation output provides 5 VDC / 200 mA or 12 VDC / 200 mA maximum to power compatible low-power external sensors. Configurable sensor warm-up time activates sensors before measurement.

Autonomous battery operation

An ultra-low-power microcontroller manages sampling, logging and communications, activating the modem and measurement subsystems only when required. An internal lithium thionyl chloride battery supports operation for up to 10 years, depending on sensor power requirements, sampling and transmission intervals, network conditions and the deployment environment. A user-enabled Coulomb meter monitors battery consumption.

Tilt sensing

An optional three-axis digital accelerometer measures angle declination for applications requiring tilt monitoring.

IoT connectivity and security

NB-IoT / LTE-M cellular connectivity transmits MQTT messages to your configured cloud platform. TLS 1.2 with user-defined certificates supports secure communication from field to cloud.

Setup and remote management

Configure scaling, sampling, timing and operating parameters locally through USB serial using the ASCII command set and Windows utility. Remote configuration and operation are also supported. Sampling and transmission intervals are independently configurable to suit the monitoring application.

Applications

• Water level monitoring
• Water quality monitoring
• Fully submerged and marine monitoring installations
• Remote water resources telemetry
• Oil and gas distribution monitoring with compatible sensors

Contact Infinite to discuss sensor compatibility and your deployment requirements.

Introduction

The REye-210-BLE is a BLE radar water level sensor using 60GHz pulsed coherent radar technology. It can be used to monitor the level of sea, lakes, rivers and creeks, with a narrow field of view and fast measurement response time.

The sensor incorporates an ultra-low power microcontroller for data sampling, subsystem activation and overall system control, and can operate from its lithium battery for up to 5 years.

Bluetooth Low Energy interface

The REye-210-BLE advertises the measured level over Bluetooth Low Energy (BLE) every 5 minutes. Each BLE advertisement reports the measured level in millimetres (mm), together with the sensor’s Mac ID and RSSI signal quality.

BLE advertisements can be collected by a compatible BLE gateway and forwarded to MQTT or cloud platforms.

Enclosure and installation

The REye-210-BLE is housed in a PVC (IP68) enclosure for outdoor use, with quick and easy installation and fully battery-powered operation — no external power or wiring required.

Applications

• Water level at rivers, lakes, sea, gulleys
• Flood monitoring
• Silo dry level monitoring
• Tank wet level monitoring

Introduction

The REye-200 is a radar water level sensor using 60GHz pulsed coherent radar technology. It can be used to monitor the level of sea, lakes, rivers and creeks, with a narrow field of view and fast measurement response time.

The sensor incorporates an ultra-low power microcontroller for data sampling, subsystem activation and overall system control, and can operate on a Lithium Thionyl battery supplying system for up to 10 years.

Modbus interface

The REye-200 is a low power RS485 Modbus radar sensor measuring distance to target, with a Modbus ASCII interface (9600 baud default, address 1) that connects to any device, and can be combined with a variety of Infinite’s products.

It is fully integrated with Itron City Edge, Cumulocity, Microsoft Azure, Amazon AWS, Losant and any platform via MQTT, using an ADS-300 NB-IoT/LTE-M or ADS-410 Itron RTU.

Enclosure and installation

The sensor is housed in a PVC enclosure rated IP67/68 for outdoor use, with an internal antenna and a 1.5 m 4-wire cable. Wiring: Green – RS485 A+, White – RS485 B, Brown – Power + (12VDC), Yellow – Ground.

Applications

• Water level at rivers, lakes and sea
• Flood monitoring
• Silo dry level monitoring
• Tank wet level monitoring

Introduction

MATI-100 and MATI-100 Ex are battery-powered 5-megapixel IoT cameras for remote visual monitoring. They connect to AERINOS ADS-3xx NB-IoT/LTE-M RTUs through I²C, adding high-resolution images to field telemetry.

Both models capture JPEG images at up to 2592 × 1944 pixels using a low-distortion M12 3.2 mm lens, with optional 2 MP and 640 × 480 resolution configurations available to enable faster transmission. Images are transferred via MQTT for visual inspection, cloud storage, and subsequent AI or machine-learning analysis.

Two models for different installations

MATI-100 is the compact outdoor model, with an IP66 polycarbonate enclosure, dimensions of 119 × 119 × 62 mm and a weight of 0.1 kg. It is suited to smart city monitoring, security, precision agriculture and plant or insect observation.

MATI-100 Ex adds IR night vision and a stainless-steel Ex enclosure rated IP66/IP68. Measuring 128 × 128 × 106 mm and weighing 2 kg, it supports visual monitoring of sewers, water infrastructure, pipes, rail lines and structures.

Image capture and MQTT transfer

The 5 MP CMOS sensor provides image enhancement and JPEG output. Compressed image files are specified at less than 500 Kbytes, supporting transmission over NB-IoT or LTE-M through the connected RTU. MQTT makes the images available to compatible platforms for inspection and further processing.

Battery-powered field operation

The camera is powered at 3.3 V from the connected ADS-3xx RTU. Specified power consumption is 0.8 W, with a maximum current of 200 mA. This arrangement supports visual monitoring at locations without a mains supply.

Setup and enclosure

The cameras are supplied preconfigured for operation. Choose MATI-100 for a lightweight polycarbonate outdoor enclosure, or MATI-100 Ex for stainless-steel construction and IR night vision. Both models operate from -10°C to +55°C.

Applications

• Security and safety monitoring
• Smart city visual telemetry
• Image acquisition for AI and machine-learning analysis
• Precision agriculture, plant monitoring and insect observation
• Water, sewer and pipe monitoring
• Railway and structural inspection

Introduction

ADS-700 is an ultra-low-power NB-IoT/LTE-M RTU and end node for autonomous sensor monitoring. It combines cellular connectivity with SDI-12, RS-485 Modbus and Bluetooth Low Energy (BLE) sensor interfaces. An ARM M33 microcontroller manages data sampling, logging and communications.

The unit incorporates three digital inputs (one also usable as a pulse counter), one 12-bit analog input, a 3-axis accelerometer with gyroscope, a temperature sensor and a coulomb meter for battery consumption monitoring. An internal 13 Ah lithium-thionyl battery supports autonomous operation for up to 10 years, depending on sensor load, sampling and transmission settings, and network conditions. External operation is available through a 5 V USB supply.

SDI-12 Serial Bus

ADS-700 supports SDI-12 version 1.2 and collects up to 15 measurement channels from multiple sensors. This interface is suitable for environmental monitoring, water management and precision agriculture.

RS-485, Modbus

The RS-485 interface supports data acquisition from Modbus sensors for up to 10 measurement channels. Modbus ASCII is supported.

Bluetooth Low Energy

BLE enables local wireless configuration and telemetry from multiple BLE sensors, allowing wired and wireless measurements to be collected by the same unit.

Data acquisition and alarms

Sampling and transmission intervals are user-configurable, allowing measurements to be recorded at a different rate from data uploads. Adjustable sensor warm-up time powers external sensors before a measurement. Threshold alarms are available for digital and analog channels.

Tilt sensing and battery monitoring

The built-in accelerometer and gyroscope support tilt measurement and alarming. The internal temperature sensor provides device temperature measurements, while the user-enabled coulomb meter tracks battery consumption.

Transducer excitation

A user-adjustable 5 V / 12 VDC excitation output supplies low-power external sensors, with a maximum current of 200 mA at either voltage.

IoT connectivity and security

ADS-700 supports MQTT and LwM2M/SenML JSON messaging (RFC 8428), with TLS 1.2 and user-defined certificates for secure communications. The cellular modem supports LTE Cat-M1 / NB-IoT, with 2G fallback and GPS/GNSS capabilities depending on the modem variant. Network availability and supported services depend on the deployment region and operator.

Setup and remote management

Configure the unit locally through USB serial or BLE using ASCII commands for scaling, timing and operating parameters. Remote configuration and control are also supported. Low-power operation activates the modem and sensor subsystems as required for acquisition and data transfer.

Compatible camera

The optional Mati-100 battery-powered 5-megapixel IoT camera connects to ADS-7/3xx devices through I²C. It provides JPEG images at up to 2592 × 1944 pixels, transferred via MQTT, for visual inspection and image analysis applications.

Applications

• Weather conditions and environmental monitoring
• Water and wastewater level and quality monitoring
• Structural and tilt monitoring
• Precision agriculture, greenhouse monitoring and irrigation systems
• Smart city monitoring
• Oil and gas distribution
• Building management and home automation
• Factory automation
• Power grid and cable fault monitoring
• Security systems and asset monitoring

Introduction

ADS-300 is an ultra low power, battery powered NBIoT, LTE-M end node. The ADS-300 supports SSL, is available for global deployment and can be used with any major Cloud IoT platform like Microsoft Azure IoT Hub, Amazon Web services, Mosquitto MQTT, etc. It incorporates two inputs, one digital with pulse counter capability and one analog, as well as multiple excitation options for powering transducers. The ADS-300 supports SDI12 and Modbus sensors. A D-size Lithium Thionyl battery provides autonomous operation for over 10 years.

SDI-12 Serial Bus

SDI-12 is an asynchronous, ASCII, serial communications protocol that was developed for intelligent sensor instruments that typically monitor environmental, structural engineering and precision agriculture data. The communication is achieved by digital communications. The addressing system allows data recorder to communicate with several microprocessor-based sensors over a single line. ADS-300 is compliant to the SDI-12 Standard Version 1.2 and supports extended commands for sensor configuration, in terminal mode. ADS-300 can collect data from several SDI-12 sensors for a total amount of 15 measurement channels.

RS-485, MODBUS

ADS-300 supports acquisition from sensors with RS-485 interface, using the popular MODBUS protocol (RTU & ASCII). Up to 8 measurement channels from several sensors are supported.

Transducer excitation

The unit provides multiple excitation options for measuring transducers.

Applications

• Weather conditions & environmental monitoring
• Water/wastewater level & quality
• Structural engineering
• Precision Agriculture
• Smart City
• Oil & Gas
• Building Management
• Factory Automation
• Power Grid
