REye-210-BLE

Overview

Introduction

The REye-210-BLE is a BLE radar water level sensor using 60GHz pulsed coherent radar technology. It can be used to monitor the level of sea, lakes, rivers and creeks, with a narrow field of view and fast measurement response time.

The sensor incorporates an ultra-low power microcontroller for data sampling, subsystem activation and overall system control, and can operate from its lithium battery for up to 5 years.

Bluetooth Low Energy interface

The REye-210-BLE advertises the measured level over Bluetooth Low Energy (BLE) every 5 minutes. Each BLE advertisement reports the measured level in millimetres (mm), together with the sensor’s Mac ID and RSSI signal quality.

BLE advertisements can be collected by a compatible BLE gateway and forwarded to MQTT or cloud platforms.

Enclosure and installation

The REye-210-BLE is housed in a PVC (IP68) enclosure for outdoor use, with quick and easy installation and fully battery-powered operation — no external power or wiring required.

Applications

  • Water level at rivers, lakes, sea, gulleys
  • Flood monitoring
  • Silo dry level monitoring
  • Tank wet level monitoring

Specifications

Ordering Codes

Code Description
REye-210-BLE 60GHz BLE water level radar sensor

Technical Characteristics

Characteristic Value
Power supply Lithium battery
Active power ≤5 mW
Transmit frequency 60 GHz
Detection range 0.3–10 m
Resolution 1 mm
Accuracy +/- 1-2 cm
Connectivity Bluetooth Low Energy (BLE), up to 100 m line of sight
Operating temperature -40°C … +85°C
Protection IP68
Dimensions 40 x 40 x 50 mm
Weight 0.06 kg
Enclosure PVC (IP68), outdoor use

Sample BLE Advertisement

Mac ID Timestamp Level (mm), RSSI
c3b350181489 04/08/2026 14:12:08 2043, 081
04/08/2026 14:17:08 2055, 081
04/08/2026 14:22:08 2033, 083

Downloads

Product Datasheets

Document Link
REye-210-BLE Datasheet V1 Download REye-210-BLE datasheet V1 (PDF)
